S206 set top box

Specification

Input Frequency:177.5～860MHz UHF & VHF

Input Impedance:75Ω

Bandwidth:5,6,7 or 8 MHz

Input Level:-25～-85 dBm

CHANNEL DECODING

Waveform:COFDM

Demodulation:QPSK,16QAM,64QAM,128QAM,256QAM

FEC: 1/2, 3/5,2/3,3/4,4/5,5/6

Mode: 1K,2K,4K, 8K,16K,32K

Guard: 1/4, 19/256,1/8,19/128, 1/16, 1/32,1/128

 TUNER –S2

lnput frequency 950~2150 MHz,Symbol Rate 2~45MB/S

SCPC&MCPC receivable from C/Ku band satellites

Demodulation:QPSK,8PSK

 DEMULTIPLEXER

Standard: ISO/IEC 13818-1

Input Max. Bit Stream Rate: 60Mbps(Serial)/7.5MBps(Parallel)

 VIDEO DECODING

Standard: ISO/IEC 13818-2 MPEG-2 MP@ML

Aspect ratio: 4:3, 16:9

Video Resolution:576i,576p,480i,480p,720p,1080i,1080p

AUDIO DECODING

Standard: ISO/IEC 13818-3

Output Mode: Left channel, Right channel, Stereo

Sampling Frequency: 32, 44.1, 48KHz
